Test & Measurement Cable Assemblies
- Extreme high frequency transmission.
- Significant electrical performance.
- Excellent durability and reliability.
Product Specifiction
|
Cable Type |
1.0mm |
1.35mm |
1.85mm |
2.4mm |
2.92mm |
3.5mm |
SMA |
N |
|
|
Impedance (Nominal) Ω |
50±1 |
||||||||
|
Maximum Frequency (GHz) |
110 |
90 |
67 |
50 |
40 |
26.5 |
26.5 |
18 |
|
|
Overall Diameter (mm) |
|||||||||
|
General Type (HG) |
N/A |
N/A |
2.3 |
3.3 |
4.1 |
5.0 |
5.0 |
5.0 |
|
|
Flexible Type (HS) |
4.3 |
4.3 |
7.1 |
7.1 |
7.1 |
8.2 |
8.2 |
8.2 |
|
|
Universal Type (HF) |
3.5 |
3.5 |
6.2 |
6.2 |
6.2 |
7.3 |
7.3 |
7.3 |
|
|
VSWR |
Typical |
1.3 |
1.3 |
1.2 |
1.2 |
1.2 |
1.2 |
1.2 |
1.2 |
|
Spec. |
1.4 |
1.4 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
|
|
Amplitude Stability (dB) |
Typical |
±0.07 |
±0.07 |
±0.05 |
±0.05 |
±0.05 |
±0.05 |
±0.05 |
±0.05 |
|
Spec. |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
|
|
Phase Stability (°) |
Typical |
±15 |
±15 |
±4 |
±8 |
±4 |
±3 |
±3 |
±2 |
|
Spec. |
±2 |
±2 |
±8 |
±11.5 |
±8 |
±5 |
±5 |
±3 |
|
|
Insertion Loss (dB/M) |
15 |
15 |
5.7 |
3.3 |
2.4 |
1.6 |
1.6 |
1.3 |
|
|
Time Delay (Nominal) (ns/M) |
4.28 |
4.28 |
4.28 |
4.28 |
4.28 |
4.33 |
4.33 |
4.33 |
|
|
Velocity of Propagation (%) (Typical) |
78 |
78 |
78 |
78 |
78 |
81 |
81 |
81 |
|
|
Minimum Bend Radius (mm) |
|||||||||
|
General Type (HG) |
N/A |
N/A |
15 |
20 |
20 |
12.7 |
12.7 |
12.7 |
|
|
Flexible Type (HS) |
15 |
15 |
25 |
25 |
25 |
25 |
25 |
25 |
|
|
Universal Type (HF) |
15 |
15 |
25 |
25 |
25 |
25 |
25 |
25 |
|
|
Temperature Range (℃) (General Type) |
-55 to 125 |
||||||||
