Frontlynk

Properties/Series

3.5mm

2.92mm

2.4mm

1.85mm

Working Frequnecy

DC~26.5GHz

DC~40GHz

DC~50GHz

DC~67GHz

VSWR(Typical/Maximum)

1.2/1.3

1.2/1.3

1.2/1.3

1.2/1.3

Phase Stability(°)(Typical/Maximum)

±2/±4

±2/±4

±2/±4.5

±4/±8

Amplitude Stability(dB) (Typical/Maximum)

±0.04/±0.1

±0.02/±0.1

±0.03/±0.1

±0.04/±0.1

Minimum bend radius

57.1mm

Temperature

Lab   conditions

Lengths(inches)

25", 36", 48" and customized
